ITA-1711 Intel® Celeron™J1900 Compact System Dual Gigabit Ethernet LAN and Dual Display
    ITA-1711 Intel® Celeron™J1900 Compact System Dual Gigabit Ethernet LAN and Dual Display
    ITA-1711 Intel® Celeron™J1900 Compact System Dual Gigabit Ethernet LAN and Dual Display
    ITA-1711 Intel® Celeron™J1900 Compact System Dual Gigabit Ethernet LAN and Dual Display

    ITA-1711 Intel® Celeron™J1900 Compact System Dual Gigabit Ethernet LAN and Dual Display

    Call for Price

    ITA-1711 Intel® Celeron™J1900 Compact System Dual Gigabit Ethernet LAN and Dual Display

    SKU: ITA-1711 Category:

    Please click the link below to open the PDF datasheet

    View Datasheet

    • Fanless, Intel® Celeron™ J1900, 2.0 GHz Quad Core Compact System
    • ƒƒ Onboard 4G DDR3 Memory and optional NVRAM
    • ƒƒ Supports up to 2 x LAN, 6 x USB, 14 x COM ports
    • ƒƒ Supports 1 x USB 3.0 port
    • ƒƒ Replaceable secondary display output (VGA2/DVI-D/LVDS)
    • ƒƒ Support dual full HD resolution video output
    • ƒƒ Serial ports support RS-232/422/485 with automatic flow control
    • ƒƒ Support up to 24 in, 24 out Digital IO


      Processor System

    • CPU: Intel® Celeron™ J1900
    • Max Speed: 2.0 GHz
    • L2 Cache: 2 MB
    • Core Number: 4
    • BIOS: AMI SPI 64Mb

      • Memory

    • Technology: Dual channel DDR3 1333
    • Capacity: Onboard 4 GB (Up to total 8GB with SODIMM)

      • Graphics

    • Chipset: Embedded Gen 4+GFX Core
    • VRAM: Shared system memory up to 256 MB SDRAM
    • Dual Display:

      • 2 x VGA or VGA + DVI-D or VGA + LVDS
      Single channel max: 2048 x 1536 @ 60Hz
      Dual channel max: 1920 x 1080 @ 60Hz

    • LVDS (optional): Support 18bit /24bit dual channel up to 1920 x 1080 @ 60Hz

      • Ethernet

    • Interface: 10/100/1000 Mbps
    • Controller: 2 x Intel I211
    • Connector: 2 x RJ-45

      • Storage

    • NVRAM: 1 Mb FRAM(Optional)
    • Internal: 1 x M-SATA socket

      • Support 1 x 2.5″ HDD/SSD (Optional)

    • External: 1 x Easy Swap SATA Slim/CompactFlash Module

      • I/O Interface

    • Main Display: VGA1
    • Secondary Display: VGA2 / DVI-D / LVDS
    • LAN: 2
    • USB: 6 (5 x USB 2.0, 1 x USB 3.0)
    • COM: 10 x RS 232/422/485 ports with automatic flow control

      • (Up to 14 ports with additional 4 optional RS-232 Serial ports)

    • Digital I/O: 1 x 24 bit GPIO (48 bit GPIO optional)
    • Audio: 1 x Speaker out with 2x4w amplifier, 1x Mic in
    • Reserved area (front panel): 1 (LPT, DIO2, PS/2 optional)

      • Expansion Slots

    • Mini PCIe: 1

      • Power

    • Power Input Voltage: DC 9 V ~ 36 V input

      • Watchdog Timer

    • Output System: reset
    • Interval: Programmable 1~255 sec/min

      • Environment

    • Temperature Operating (W/O HDD): -25 ~ 60° C
    • Temperature Operating (With HDD): 0 ~ 40° C
    • Temperature Non-Operating: -40 ~ 85° C

      • Physical Characteristics

    • Dimensions (W x H x D): 200 x 100 x 190 mm
